Tektronix DPO70000 Series

Appendix C: Factory Default Setup Values
Command Default Values
TRIGger:{A|B}:LOGIc:THReshold:CH<x> CH4 = 1.2000
TRIGger:A:MODe AUTO
TRIGger:{A|B}:PULse:CLAss GLITCH
TRIGger:{A|B}:PULse:GLItch:POLarity POSITIVE
TRIGger:{A|B}:PULse :GLItch:T RIGIF ACCEPT
TRIGger:{A|B}:PULse :GLItch:W ID th
2.0000E-9
TRIGger:{A|B}:PULse :RU NT:POLarity POSITIVE
TRIGger:{A|B}:PULse:RUNT:THReshold:HIGH
1.2000
TRIGger:{A|B}:PULse:RUNT:THReshold:LOW
800.000
0E-3
TRIGger:{A|B}:PULse :RU NT:WHEn OCCURS
TRIGger:{A|B}:PULse :RU NT:WIDth
2.0000
E-9
TRIGger:{A|B}:PULse :SOU rc e CH1
TRIGger:{A|B}:PULse:TIMEOut:POLarity STAYSHIGH
TRIGger:{A|B}:PULse :TIM EOut:T IMe
2.00
00E-9
TRIGger:{A|B}:PULse:TRANsition:DELTATime
2.00
00E-9
TRIGger:{A|B}:PULse:TRANsition:POLarity PO SITIVE
TRIGger:{A|B}:PULse :TR A Nsition:THReshold:HIGH
1.
2000
TRIGger:{A|B}:PULse:TRANsition:THReshold:LOW
80
0.0000E-3
TRIGger:{A|B}:PULse:TRANsition:WHEn FASTERTHAN
TRIGger:{A|B}:PULs e :W IDth:HIGHLimit
2
.0000E-9
TRIGger:{A|B}:PULse :W IDth:LOWLimit
2.0000E-9
TRIGger:{A|B}:PULse :W IDth:POLarity POSITIV E
TRIGger:{A|B}:PULse :W IDth:W HEn
WITHIN
TRIGger:{A|B}:PULse :WINdow:THReshold:HIGH
1.2000
TRIGger:{A|B}:PULse:WINdow:THReshold:LOW
800.0000E-3
TRIGger:{A|B}:PULse :W INdow :WIDTH
2.0000E-9
TRIGger:A:PULse:W INdow:POLarity
EITHER
TRIGger:A:PULse:W INdow:POLarity:CH<x>
EITHER
TRIGger:A:TYPe EDGE
TRIGger:A:VIDeo:CU S Tom :F O R Mat INTE RLACED
TRIGger:A:VIDeo:FIELD ALLFIELDS
TRIGger:A:VIDeo:HOLdoff:FIELD
0.0000
TRIGger:A:VIDeo:LINE
1
TRIGger:A:VIDeo:POLarity NORMAL
TRIGger:A:VIDeo:SCAN
RATE1
TRIGger:A:VIDeo:SO Urce CH1
TRIGger:A:VIDeo:STANdard NTSC
TRIGger:B:BY EVENTS
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual C-11
