Tektronix DPO70000 Series Programmer's Manual

Appendix C: Factory Default Setup Values
Command Default Values
TRIGger:B:EVENTS:COUNt
2
TRIGger:B:PULse:WINdow:POLarity
EITHER
TRIGger:B:PULse:WINdow:POLarity:CH<x>
EITHER
TRIGger:B:STATE
0
TRIGger:B:TIMe
16.0000E-9
TRIGger:B:TYPe EDGE
Vertical Default Values
The f ollowing table lists the Vertical factory default setup values.
Command Default Values
CH&lt;x>:BANdwidth
500.000
0E+6
CH<x>:COUPling DC
CH<x>:DESKew
0.0000
0
CH<x>
:LABel:NAMe
“”
CH<x
>:LABel:XPOS
CH1 =
1.0000
CH1 =
2.2000
CH2
= 1.8000
CH3
= 1.4000
CH<x
>:LABel:YPOS
CH
4 = 1.000
CH
<x>:OFFSet
0.0000
C
H<x>:POSition
0.0000
C
H<x>:PROBECOntrol
A
UTO
CH<x>:PROBEFunc:EXTAtten
1.0000
CH<x>:PROBEFunc:EXTUnits
“V”
CH<x>:SCAle
100.0000E-3
CH<x>:TERmination
1.0000E+6
REF<x>:LABel:NAMe “”
REF<x>:LABel:XPOS
1.0000
REF<x>:LABel:YPOS
-1.0000
SELect:<wfm> CH1 = 1
CH2 = 0
CH3 = 0
CH4 = 0
SELect:CONTROl CH1
Waveform Default Values
The following table lists the Waveform factory default setup values.
C-12 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
