Tektronix DPO70000 Series Programmer's Manual

Command Groups
Command
Description
WFMInpre:NR_
Pt
Sets or returns the number of points in the
transmitted waveform record
WFMInpre:PT_Fmt
Sets or returns the point format of incoming
waveform dat
a
WFMInpre:P
T_Off
Sets or retu
rns the trigger point within the
incoming waveform data
WFMInpre:W
FId
Allows a waveform extracted from the
instrument to be more easily sent back
WFMInpre:XINcr
Sets or returns the horizontal sampling
interval
between incoming waveform points
WFMInpre:XUNit
Sets or re
turns the horizontal units of the
incoming wa veform
WFMInpr
e:XZEro
Sets or returns the (sub-sample) time
between the trigger sample and the
occurre
nce of the actual incoming waveform
trigger
WFMInp
re:YMUlt
Sets or returns the vertical scale factor, per
digitizing level, of the incoming waveform
point
s
WFMIn
pre:YOFf
Sets o
r returns the vertical position of the
incoming waveform in digitizing levels
WFMI
npre:YUNit
Sets or returns the vertical units of the
incoming wa veform
WFMInpre:YZEro
Sets or returns the offset of the incoming
wav
eform
WF
MOutpre?
Re
turns the waveform formatting data for the
waveform specified by the DATA:SOURCE
command
WFMOutpre:BIT_Nr Sets or returns the number of bits per
w
aveform point that outgoing waveforms
contain
WFMOutpre:BN_Fmt Sets or returns the format of binary data for
the waveform
WFMOutpre:BYT_Nr Sets or returns the data width for the
waveform
WFMOutpre:BYT_Or Sets or returns the byte order of waveform
points
WFMOutpre:ENCdg Sets or returns the type of encoding for
outgoing waveforms
WFMOutpre:NR_Pt? Returns the number of points for the
waveform transmitted in response to a
CURVe? query
WFMOutpre:PT_Fmt? Returns the point format for the waveform
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-71
