Tektronix DPO70000 Series Programmer's Manual

Command Groups
Command
Description
ZOOm:HORizontal:SCAle Sets or queries the zoom horizontal scale
factor around which the zoom waveform is
displayed
ZOOm:MATH<x
>:HORizontal:POSition
Sets or queri
es the horizontal position of the
specified math waveform
ZOOm:MATH <x> :HO Rizontal:SC Ale Sets or queries the zoom horizontal scale
factor of the specified math waveform
ZOOm:MATH<x>:VERTical:POSition Sets or queries the vertical position of the
specified m
ath waveform
ZOOm:MAT
H<x>:VERTical:SCAle
Sets or qu
eries the vertical scale of the
specified math waveform
ZOOm:MODe Sets or returns the zoom mode
ZOOm:REF<x >:HORizontal:POSition Sets or queries the horizontal position of the
specified reference w aveform
ZOOm:REF<x>:HORizontal:SCAle Sets or queries the zoom horizontal scale
factor
of the specified reference waveform
ZOOm:
REF<x>:VERTical:POSition
Sets o
r queries the vertical position of the
specified reference w aveform
ZOOm:REF<x>:VERTical:SCAle Sets or queries the zoom vertical scale of the
specified reference w aveform
ZOOm:SCROLL:DIREction Sets or returns the direction of AutoScroll for
zoom
ed waveforms
ZOO
m:SCROLL:LOCk
Set
s or r eturns the state of Scroll Lock, on
or off
ZOOm:SCROLL:SPEED Sets or returns the speed of AutoScroll for
zoomed waveforms
ZOOm:STATE Specifies or returns a trace as zoomed, on
o
roff
Z
OOm:VERTical:POSition
S
ets or queries the vertical position around
which the zoom waveform is displayed.
It is freely movable w ithin the confines of
the acquired waveform (0% to 100%) and
measured from left to right of the acquired
waveform
ZOOm:VERTical:SCAle Sets or queries the zoom vertical scale
factor around which the zoom waveform is
displayed
ZOOm:ZOOM<x> Sets or returns zoom factors for the specified
zoom
ZOOm:ZOOM<x>:<wfm>:HORizontal:
POSition
Sets or returns the horizontal zoom position
for the specified waveform in the specified
zoom
ZOOm:ZOOM<x>:<wfm>:HORizontal:SCAle Sets or returns the horizontal zoom scale of
the specified waveform in the specified zoom
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-73
