Tektronix DPO70000 Series Programmer's Manual

Command Groups
Command
Description
ZOOm:ZOOM<x >:<wfm > :HO Rizontal:
TIMEPosition
Sets or queries the zoom horizontal position
of the specified waveform for the specified
zoom in time
ZOOm:ZOOM<x
>:<wfm>:VERTical:
POSition
Sets or retur
ns the vertical zoom position for
the specifi ed waveform in the specified zoom
ZOOm:ZOOM<x>:<wfm>:VERTical:SCAle Sets or returns the vertical zoom scale for
the specifi ed waveform in the specified zoom
ZOOm:ZOOM<x>:SCROLLLock Sets or returns Scroll Lock for the specified
zoom
ZOOm:ZOO
M<x>:<wfm>:DISplay
Sets or re
turns the display of the specified
waveform for the specifi ed zoom
ZOOm:ZOO M<x >:S TATE Sets or queries the specified zoom on or off,
where x is an integer from 1 to 4 representing
the desi
red zoom window
2-74 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
