X35 Console General Operations
8.31
6000 Series Air Seeder
Tire Type
Theoretical Wheel Factor
ft/pulse m/pulse
900/60R32 R1-W Lug 0.207 0.0631
800/65R32 R1-W Lug 0.209 0.0637
650/75R34 R1-W Lug 0.206 0.0628
560/65D24
Softrac 0.208 0.0634
520/85R38
R1 Lug 0.207 0.0631
480/80R38 R1 Lug 0.203 0.0619
30.5LX32 AWT 0.208 0.0634
30.5LX32 R2 Rice Lug 0.205 0.0625
30.5LX32 R1 Lug 0.208 0.0634
28LX26 AWT 0.203 0.0619
28LX26 R2 Rice Lug 0.207 0.0631
28LX26 R1 Lug 0.204 0.0622
23.1X26 AWT 0.203 0.0619
23.1X26 R2 Rice Lug 0.207 0.0631
23.1X26 R1 Lug 0.203 0.0619
20.8R38 R2 Rice Lug 0.21 0.0.064
18.4X26 AWT 0.208 0.0634
18.4X26 R2 Rice Lug 0.205 0.0625
18.4X26 R1 Lug 0.204 0.0622
18.4X38
R1 Lug 0.203 0.0619
IMPORTANT
These are theoretical values and should be
verified for accuracy as variations in tire size,
inflation pressure, etc will cause differences.
Note
The 9000 Series is not equipped with a wheel
speed sensor.
Figure 8.62 - Theoretical Wheel Factors - 6000 Series Air Seeder
