Maintenance3326−2/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
4/ 7
⇒ Fasten lifting rings 94332 to cylinder block 7 with screws 6 and tighten these
with 200 Nm.
⇒ Screw RUD-eye bolts ’RC’ into guide shoes 5.
⇒ Connect lifting tackles H
3
and H
4
(lifting capacity 750 kg each) with lifting rings
and RUD-eye bolts ’RC’.
⇒ Tauten lifting tackles H
3
and H
4
as far as the guide shoes do not rest any more
on crosshead pin.
⇒ Remove holding plates from crosshead pin according to the instructions given
in 3326−1.
E
I
I
013.241/05
013.242/05
I - I
7
94332
6
H
3
8
94324
2
RC
5
H
4
R
C
5
2010
Removal and Fitting of a Crosshead Pin
