Maintenance6606−1/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
6/ 7
⇒ Slowly lower the cooler using spur-geared chain block H
1
until the latter car-
ries no more load. The weight of the cooler having been taken over by manual
ratchet H
4
.
⇒ Carefully tilt the cooler until it is hanging on the engine crane.
⇒ Remove lifting plate 94663−IL
⇒ Carry the cooler away and remove all tools.
G
H
H
4
WCH00115
94663−IL
2010 / 50−D
Removal and Fitting of Scavenge Air Cooler (with Integrated Lifting IL
