Maintenance
6708−1/A1
RT-flex50-D
Wärtsilä Switzerland Ltd
9/ 10
018.331/09
M
H
1
H
2
H
3
⇒ Completely withdraw the water separator by means of manual ratchet H
3
,
while continuously following with spur-geared chain blocks H
1
, H
2
and adjust-
ing the height correspondingly.
018.332/09
N
H
1
⇒ Remove manual ratchet H
3
and detach spur-geared chain block H
2
, then re-
move lifting and withdrawing gear 94667 and bracket 94667c.
⇒ Carry the water separator towards the bottom using spur-geared chain blocks
H
1
.
2010
Removal and Fitting of Water Separator
