OmniAccess 5740 Unified Services Gateway Web GUI Users Guide
CONFIGURING SNMP PARAMETERS
Follow the procedure below to configure SNMP parameters:
Step 1: Enable SNMP Service.
To enable the SNMP service, check SNMP Service check box.
Step 2: Configure Community Settings.
1. Select the Traps Enable check box to enable SNMP trapping.
2. Enter the Read Community/Read-Write Community string for the SNMP agent.
3. Click Apply to configure Community Settings.
Step 3: Configure SNMP trap host. This is to configure the trap destination where
the agent will send the snmp traps.
If you have checked the Traps Enable check box, configure SNMP trap hosts. To
configure new SNMP trap hosts, click New Trap Host in the Trap Host
Configuration box. This populates fields to add SNMP trap host details.
1. The host IP address to which the trap messages are to be sent in the in the IP
Address field.
2. Enter the notification host's UDP port number in the Port field.
3. Select the SNMP version from the SNMP Version drop-down list.
4. Set the SNMP community string in the Community String field.
Note: You can configure a maximum of 3 SNMP trap receivers.
5. Click Apply to add SNMP trap host.
E
DITING A SNMP TRAP HOST
1. Click Edit icon in the Action column against the trap host that is to be edited.
2. Enter the new host details in the respective columns.
IP Address, Port, SNMP Version, and Community String details.
3. Click Apply to save changes, or Cancel to retain the original settings.
D
ELETING A SNMP TRAP HOST
1. Click Delete icon in the Action column against the trap host to be deleted.
2. Confirm at the prompt to delete the SNMP trap host.
