3. Set Internal Mapping. This allows you to configure a DNAT with host IP address or
an IP address pool.
•Select Host radio button.
i. Enter the IP address of the host in the Host IP field.
ii. Configure port number for a DNAT by selecting Port check box. Enter the
port number. The range for the port is 1-65535. This is optional.
•Select Pool radio button.
i. Select the list name from the Pool Name list.
ii. Configure port number for a DNAT by selecting Port check box. Enter the
port number. The range for the port is 1-65535. This is optional.
4. Click Apply to configure NAT rules for the newly created DNAT policy or Cancel
to return to the NAT Policy page.
Address and Port Translation
Figure 97: Firewall: NAT - Destination NAT Configuration - NAT Rule -
Address & Port Translation
