OmniAccess 5740 Unified Services Gateway Web GUI Users Guide
TRANSFORM SET
A transform set represents a certain combination of security protocols and
algorithms. During the IPSec security association negotiation, the peers agree to
use a particular transform set for protecting a particular data flow.
This page allows you to add/edit transform sets.
V
IEWING TRANSFORM SET
Follow the procedure below to view Transform Sets page.
Step 1: Launch the Web GUI tool.
Step 2: From the USGM menu bar, click Configure. All submenu/links under
Configure are displayed in the left navigation panel.
Step 3: Click VPN IPSec sub-menu.
The VPN IPSec has four tabs: IPSec Wizard, Preshared Keys, IKE Policy, and
Transform Set.
Select Transform Set tab. Transform Sets page is displayed in the center panel.
Figure 132: VPN IPSec: Transform Sets
The table below provides description for Transform Sets page.
Table 23: Transform Set Field Description
Field Description
T
RANSFORM SETS
Name Name of the transform set.
Encapsulation Encapsulation set for the transform set.
IPSec Policy Reference Lists IPSec policy/policies to which the
particular IKE policy is attached.
Action Provides option to edit and/or delete a
transform set.
New Create new transform set.
