OmniAccess 5740 Unified Services Gateway Web GUI Users Guide
FIREWALL AND SECURITY
This page allows to view the Filters, NAT, DOS Attack, and Firewall Policy settings
configured on your system.
F
ILTERS
This page displays information about an IP Filter. The Filter Params section
displays the description of the IP Filter selected. The Configured Actions section
displays the actions that have been configured. The Interface Bindings section
displays information about the interfaces to which the filter policies have been
applied. On clicking the Show Policy Statistics, global statistics for that Filter
policy is displayed.
V
IEWING FILTER STATISTICS
Follow the procedure below to view the Filter statistics.
Step 1: Launch the Web GUI tool.
Step 2: From the USGM menu bar, click Monitor. All submenu/links under
Monitor are displayed in the left navigation panel.
Step 3: Click Firewall and Security sub-menu.
The Firewall and Security has four tabs: Filters, NAT, DOS Attack and Firewall
Policy. By default, Filters tab is selected and Filter page is displayed in the center
panel.
Step 4: Select the filter whose statistical information is to be viewed from the
Filter List drop down list. The filter page displays the parameters, actions and the
interface information for the selected filter.
Figure 216: Monitor: Firewall and Security - Filters
