The table below provides description for Firewall Session Statistics page.
Table 44: Firewall Session Statistics Field Description
Field Description
F
IREWALL SESSION STATISTICS
Firewall Session Summary
TCP Sessions Number of TCP sessions maintained by
the firewall module
UDP Sessions Number of UDP sessions maintained by
the firewall module
ICMP Sessions Number of ICMP sessions maintained by
the firewall module
GRE Sessions Number of GRE sessions maintained by
the firewall module
Total Sessions Total number of sessions maintained by
the firewall module
Free Sessions Number of free sessions available to the
firewall module
Firewall Session Details Displays details of each of the above
sessions.
Source Address IP address of the source
Source Port Port number at the source
Destination Address IP address of the destination
Destination Port Port number at the destination
Protocol The type of protocol used for the session
State The state the session is in based on the
protocol
Last Heard Time elapsed since the last data transfer
took place. This helps in deleting a
session if it has been idle for too long.
Refresh Refresh the Firewall Session Statistics
page
