QOS STATISTICS
This page displays the QoS statistics for those interfaces to which the QoS policy
is attached. The Ingress Statistics table displays the QoS statistics for the
interface in the ingress direction. The Egress Statistics table displays the QoS
statistics for the interface in the ingress direction.
Note: QoS statistics page displays only those QoS policies that are attached to the active
interfaces.
V
IEWING QOS STATISTICS
Follow the procedure below to view the QoS statistics.
Step 1: Launch the Web GUI tool.
Step 2: From the USGM menu bar, click Monitor. All submenu/links under
Monitor are displayed in the left navigation panel.
Step 3: Click QoS Statistics sub-menu.
QoS Statistics page displays the details of the QoS configured on the system in
the center panel.
Figure 230: Monitor: QoS Statistics
