EDIT IPSEC POLICY
The IPSec policy configured using the wizard can be edited/modified. Follow the
procedure to edit the IPSec policy.
1. In the VPN (IPSec) Policies page, click Edit icon in the Action column against
the IPSec policy to be edited.
2. Edit IPSec Policy page is displayed. This page displays the parameters
configured for the selected IPSec policy. Modify the required parameters.
Figure 124: VPN IPSec: IPSec Wizard - Edit IPSec Policy
Transform Set Transform set associated with the IPSec
policy.
Click on this to view the details of the
Transform-set configured for the IPSec
policy.
Attached Interface Interface to which the IPSec policy is
attached.
Action Provides option to view, edit, or delete
an IPSec policy.
Field Description
