P
RESHARED KEYS
The Preshared key is used to authenticate peers. This key is same on both the
IPSec gateways. It is denoted in the form of a key-string.
This page allows you to add/edit preshared key for IPSec policy.
V
IEWING PRESHARED KEYS
Step 1: Launch the Web GUI tool.
Step 2: From the USGM menu bar, click Configure. All submenu/links under
Configure are displayed in the left navigation panel.
Step 3: Click VPN IPSec sub-menu.
The VPN IPSec has four tabs: IPSec Wizard, Preshared Keys, IKE Policy, and
Transform Set.
Select Preshared Key tab. Preshared Key page is displayed in the center panel.
Figure 126: VPN IPSec: Preshared Keys
The table below provides field description for Preshared Keys page.
Table 21: Preshared Keys Field Description
Field Description
P
RESHARED KEYS
Peer Host IP address of the peer
Key Preshared key.
Action Provides option to edit or delete a key.
New Configure new preshared key.
