OmniAccess 5740 Unified Services Gateway Web GUI Users Guide
Alcatel-Lucent
A
TTACH FIREWALL TO AN INTERFACE
Step 1: Select the firewall policy from the firewall list.
Step 2: Click Attach Interface in the Interface Bindings table.
Fields to attach an interface is populated as shown below.
Figure 109: Firewall: Firewall Policy - Attach Interface
Step 3: Select the interface from the Interface list
Step 4: Select the direction IN/OUT.
Step 5: Click Attach to attach the selected interface to the firewall policy.
D
ELETING FIREWALL POLICY
1. Click Delete icon in the Action column against the Firewall Policy to be deleted.
2. Confirm at the prompt to delete the selected firewall policy.
Note: To delete the firewall policy, detach the firewall policy from the interface and/or
disassociate the DOS attack policy or time range.
E
DITING FIREWALL POLICY RULE
1. Select the firewall policy from the Firewall Policy Name list.
Rules already configured (DOS Attack/Intrusion rules) for the selected firewall
policy is displayed in DOS Attack Rule/Intrusion Rule Configuration table.
2. Click Edit icon in the Action column for the firewall policy rule to be edited.
3. Enter the new firewall policy rule parameters in the respective columns.
4. Click Apply to save the changes or Cancel to retain original parameters.
