A
DD MLFR INTERFACE
A typical MLFR configuration has at least two components:
• A bundle interface
• An interface running Frame Relay is made multilink-enabled and attached to the
bundle interface.
IP routing protocols as well as policies such as ACL, NAT, IDS, IPSec, etc.,
configured on an individual interface will not be effective as long as the interface is
part of the MLFR bundle. When the interface is no longer part of the bundle, the
policies configured on the individual interface become active.
Follow the below procedure to add a MLFR bundle interface.
Step 1: Click Add Logical Interface on the Interfaces page. A drop-down list
lists the logical interfaces that can be configured. Select MLFR from the list.
Configuring MLFR Bundle Interface page is displayed as shown below.
Figure 37: Interfaces - MLFR Bundle Configuration
Step 2: Configure the MLFR bundle interface by entering the bundle ID, VRF,
description, MTU, IP address and bundle identification (BID) name for the
interface.
