OmniAccess 5740 Unified Services Gateway Web GUI Users Guide
Alcatel-Lucent
T
RANSPARENT FIREWALL
This page allows you to add and/or edit Transparent Firewall (TF) policy.
OmniAccess 5740 USG Specific Overview
• OmniAccess 5740 USG supports TF between two Ethernet interfaces (Services
Engine Gigabit Ethernet).
• IP packets on the TF is subjected to L3 filters that can be applied on the ingress /
egress path on an interface.
• The TF framework allows ARP packets to be bridged across the TF'ed interfaces.
• The TF framework provides configuration for non-IP packets to be transparently
bridged across the TF'ed interfaces.
V
IEWING TF
Follow the procedure below to view TF page.
Step 1: Launch the Web GUI tool.
Step 2: From the USGM menu bar, click Configure. All submenu/links under
Configure are displayed in the left navigation panel.
Step 3: Click Firewall sub-menu.
The Firewall has the following tabs: Firewall Wizard, Filters, NAT, DOS Attack,
Transparent Firewall and Firewall Policy. Select Transparent Firewall tab.
Transparent Firewall page is displayed in the center panel.
Figure 103: Firewall: Transparent Firewall
