3. Modify the required parameters. Name and IPSec Policy Type fields cannot be
modified.
4. Select IKE policy, transform set, traffic classifier (match-list), PFS group from the
respective drop-down list.
5. Enter lifetime for the IPSec policy in seconds and KB in Lifetime in seconds and
Lifetime in KB field.
6. Peer Host displays the Peer added to the IPSec policy. Modify the same if
required under Peer Host.
• Select the Peer Host to be added to the IPSec policy from the Available
Hosts column and click the ‘>>’ button to move it to the Selected Hosts
column.
• Select as many peer hosts from the Available Hosts column and move it to the
Selected Hosts column.
The Available Hosts column lists only the hosts to which preshared key is
configured and the Selected Hosts lists the remote/peer hosts selected.
7. Click Apply to save the IPSec policy parameters, or Cancel return to VPN
(IPSec) Policies page.
8. Interface Bindings table displays the interfaces to which the IPSec policy is
attached. Modify if required.
• Click Attach in the Interface Bindings table. This populates fields to select
the interface.
• Select the interface from the list of interfaces to which you want to attach the
IPSec policy.
The same IPSec policy can be assigned to multiple interfaces, and the
same interface can be attached to multiple IPSec policies.
• Click Apply to attach the interface to the IPSec policy.
9. Click Detach icon in the Action column to detach the interface from the IPSec
policy.
10. Confirm at the prompt to detach the interface from the IPSec policy.
D
ELETING IPSEC POLICY
1. In the VPN (IPSec) Policies page, click Delete icon in the Action column against
the IPSec policy to be deleted.
2. Confirm at the prompt to delete the IPSec policy.
Note: An IPSec policy assigned to an interface cannot be deleted. To delete an IPSec policy
associated with an interface, disassociate the IPSec policy from the interface from the
Edit IPSec Policy page and then delete.
