• Set Violate Action as Drop, Transmit, or IP Mark. Select the required
option from the Violate Action drop-down list.
If you set Violate Action as IP Mark, set also the DSCP or IP
Precedence/TOS values.
i. Select DSCP radio button to set DSCP values. Select the DSCP
values from the DSCP drop down menu.
ii. Select IP Precedence/TOS radio button to set IP precedence value.
At least one IP Precedence or TOS values must be configured.
Select the IP Precedence check box and select IP Precedence value
from the drop down list. Select Type of Service check box and select
the type of service from the drop down list.
5. Click Apply to create a new Traffic Class with policing configuration.
Traffic Class with Congestion Avoidance
Note: RED/WRED is applicable only on the leaf class. If there is RED/WRED configured on
a class, then child policy can be added on the class. But if there is child attached to a
class, then RED/WRED cannot be configured on the class.
1. Click Congestion Avoidance tab in the New Traffic Class page. The following
page is displayed:
