Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway Web GUI Users Guide
5. Select the Serve Peer with IP Address option: Enable/Disable
•If Enable option is selected, enter the IP address in the IP Address field. The
entered IP address will be assigned to the peer on IPCP negotiation. If
"Negotiate IP Address with the Peer" is selected on the peer, then the IP
address assigning will be successful.
• Disable option disables Serve Peer with IP Address. This will set the flag to
accept the peer’s IP address during IPCP.
6. On some links, it may be desirable to require a peer to authenticate itself before
allowing network-layer protocol packets to be exchanged. To enable this
authentication, PPP supports authentication protocols such as PAP, CHAP, EAP
(CHAP - Challenge Authentication Protocol, PAP - Password Authentication
Protocol, EAP - Extensible Authentication Protocol). Authentication is not
mandatory.
Set the authentication protocol for authenticating the peer by selecting the option
from PPP Authentication drop-down list: Chap/Pap/Eap/None
• You can set the credentials for PPP authentication on either the server side or
client side. Select the Use below credentials for client/Use below
credentials for server check box to enter the user name and password on
the client side/server side.
i. Enter the user name and the password in the User Name and Password
fields. Confirm password in the Confirm Password field.
• Selecting None option for PPP authentication removes the authentication
protocol for authenticating the peer.
Note: Server side credentials are mandatory for CHAP/PAP/EAP authentication protocol.
7. Click Advanced Options to initiate LCP negotiation on a PPP encapsulation and
configure PPP Timers. The following pop up window is displayed:
