i. Select the state from the State drop down list: Enabled/Disabled
ii. Enter the path cost in the Cost field (range 1- 65535). The default value is 4.
Note: When two bridges compete for position as the root bridge, configure the PVST cost to
prioritize an interface.
iii. Enter the port priority in the Priority field (range 0 - 255). This priority value is
used to prioritize an interface when two bridges compete for position as the
root bridge. Default value for port-priority is 128.
iv. Click OK to configure the switch port parameters or click Cancel to cancel the
operation.
Step 12: Click Apply to save the VLAN STP configuration or click Cancel to
cancel the operation.
Step 13: The VLAN interface thus configured is displayed in the Interfaces
page.
