2.6 Checking Instrument Status
2-25
2
Before Use
The commands for checking the completion of error event register
execution are shown in Table 2.6.3-5.
Table 2.6.3-5 Commands for Checking Error Event Register Execution
Error
Event
Register
Bit
Command
2
:DISPlay[:WINDow]:TRACe:X[:SCALe]:CENTer,
:DISPlay[:WINDow]:TRACe:X[:SCALe]:SPAN,
:DISPlay[:WINDow]:TRACe:X[:SCALe]:STARt,
:DISPlay[:WINDow]:TRACe:X[:SCALe]:STOP,
[:SENSe]:BANDwidth|BWIDth[:RESolution],
[:SENSe]:SWEep:POINts,
[:SENSe][:WAVelength]:CENTer,
[:SENSe][:WAVelength]:SPAN,
[:SENSe][:WAVelength]:STARt,
[:SENSe][:WAVelength]:STOP,
: TRACe:POINts
1
:CALCulate:MARKer[1|2|3|4]:MAXimum,
:CALCulate:MARKer[1|2|3|4]:MAXimum:LEFT,
:CALCulate:MARKer[1|2|3|4]:MAXimum:NEXT,
:CALCulate:MARKer[1|2|3|4]:MAXimum:RIGHt,
:CALCulate:MARKer:MAXimum:SCENter
:CALCulate:MARKer:MAXimum:SRLevel
:CALCulate:MARKer[1|2|3|4]:MINimum,
:CALCulate:MARKer[1|2|3|4]:MINimum:LEFT,
:CALCulate:MARKer[1|2|3|4]:MINimum:NEXT
:CALCulate:MARKer[1|2|3|4]:MINimum:RIGHt
0
:DISPlay[:WINDow]:TRACe:X[:SCALe]:SPAN,
:DISPlay[:WINDow]:TRACe:X[:SCALe]:STARt,
:DISPlay[:WINDow]:TRACe:X[:SCALe]:STOP,
[:SENSe]:BANDwidth|BWIDth[:RESolution],
[:SENSe]:SWEep:POINts,
[:SENSe][:WAVelength]:SPAN,
[:SENSe][:WAVelength]:STARt,
[:SENSe][:WAVelength]:STOP,
: TRACe:POINts
The error event register can be read by
the:
STATus:EVENt:ERRor:CONDition?
.
The error event register enable register can be set and read using
the
:STATus:EVENt:ERRor:ENABle
and
:STATus:EVENt:ERRor:ENABle?
commands. To output error event
register data, set the bit corresponding to the enable register to 1.
The error event register can be set to 0 using the
*CLS
command.
The enable register of the error event register cannot be changed using
*CLS
.
