# OSI layer name Protocol
(1)
Protocols can be excluded and the content changed.
(2)
ICMP appears in case of Ping application.
4 Transport TCP, UDP
3 Network
IPv4
(1)
, IPv6
(1)
, ICMP
(2)
, ARP
2 Data Link
IEEE 802.2 LLC Type 1/ LLC1 + SNAP
(1)
,
VLAN
(1)
, PBB, MPLS-TP, MPLS,
Ethernet
(1)
1 Physical
Electrical / SFP / SFP+,
10 Mbps / 100 Mbps / 1000 Mbps / 10 Gbps,
FDX / HDX
Encapsulation affects the Ping and RFC2544/Router Latency test, i.e. Ping
replies will only be sent if the Ping request contains the same encapsulation as
the one selected.
Touching Close will save your current settings and close the dialog. The
settings done in dialog box will be reflected on the ports setup screen.
Layer configuration parameters
The settings related to each layer are described in detail below. The following
layer buttons are available:
Custom (Custom header)
Unframed
ETH (MAC header)
MPLS
MPLS-TP
PBB
VLAN
LLC1
SNAP
IPv4
IPv6
UDP
TCP
Payload
Variable
Custom header can be set on BERT application, allows users to edit the
specific area in the header. To set Custom header, touch the Custom
button in Layer 2 or select Custom in Layer 3.
