Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

[src-mask <ipv4 mask>]

IPv4 source mask address

[src-port <0-65536>]

UDP source port

[match-action {accept | drop}]

Filter match action processing

[v6-dest-address <ipv6 addr>]

IPv6 destination address

[v6-dest-pfxlen <0-128>]

IPv6 destination address prefix length

[v6-scr-address <ipv6 addr>]

IPv6 source address

[v6-src-pfxlen <0-128>]

IPV6 source address prefix length

[v6-flow-label <0-104875>]

IPv6 flow label

[ip-version <ipv4 | ipv6

| unknown>]

Specific IP version to filter

Related Commands

show cable filter (page 2652)
