Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

show ip igmp interfaces cable-mac

Purpose

Displays the current host and router configuration status for the specified cable-mac interface.

Default Access Level

Command Syntax

show ip igmp interfaces cable-mac <int>

Supplemental

Information

N/A

Parameters

<int>

The MAC identifier (valid numbers are 0-415)
