Arris C4 - Show Cable Service-Group

To Next Page

To Previous Page

Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

show cable service-group

Purpose

Provides status of the service groups for the cable-mac interface specified.

Default Access Level

Command Syntax

show cable service-group [cable-mac <int>] [mCMsg <int>] [mDSsg <int>] [mUSsg <int>]

Supplemental

Information

N/A

Parameters

cable-mac <int>

MAC identifier

[mCMsg <int>]

MAC domain cable modem service group identifier

[mDSsg <int>]

MAC domain downstream service group identifier

[mUSsg <int>]

MAC domain upstream service group identifier
