Chapter 46: Command Line Descriptions
STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide
© 2016 ARRIS Enterprises LLC. All Rights Reserved. 2484
configure router ospf * area * range
Purpose
Consolidates and summarizes IP networks in Type-3 LSAs when the C4 CMTS is defined as an Area Border Router (ABR).
Default Access Level
15
Command Syntax
configure router ospf [vrf <name>] area <area-id> range <ip-address> <mask> [advertise | not advertise]
configure router ospf [vrf <name>] area <area-id> range <ip-address> <mask> [advertise | not advertise]
no
Supplemental
Information
The default is to "advertise" these networks. To stop the consolidation and summarization of routes at an area boundary, use the no
option.
Parameters
[vrf <name>]
Name of the assigned VRF.
<area-id>
Identifier for the stub or NSSA area. The identifier can be specified as either an IP address or decimal value.
<ip-address>
IP Address
<mask>
IP Mask
[advertise
Sets the address range status to advertise and generates a Type 3 summary LSA.
| not advertise]
Set the address range status to DoNotAdvertise. Type 3 summary LSA is suppressed
