Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure logging console

Purpose

Enables the sending of system logging messages to the console and sets logging level.

Default Access Level

Command Syntax

configure logging console <level>

configure logging console <level> no

Supplemental Information

To disable sending system logging messages to the console, use the no option.

Parameters

<level>

Values of priority level are:

1 = emergency

2 = alert

3 = critical

4 = error

5 = warning

6 = notice

7 = informational

8 = debug

Related Commands

trace logging no (page 3066)

show logging console (page 2971)

show logging debug (page 2972)

show logging monitor (page 2975)
