Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

show cable proto-throttle

Purpose

Displays the specified throttle settings.

Default Access Level

Command Syntax

show cable proto-throttle [detail] [arp-nd-replies-throttled <0-65535>] [arp-nd-requests-throttled <0-

65535>]

Supplemental

Information

N/A

Parameters

[detail]

Displays all information on throttled CMs and CPEs.

[arp-nd-replies-

throttled

<0-65535>]

Displays the ARP (including ND) replies throttled count. Valid range is 0-65535.

[arp-nd-requests-

throttled

<0-65535>]

Displays the ARP (including ND) requests throttled count. Valid range is 0-65535.
