configure interface link-aggregate * isis circuit-type
Purpose
Configures the level of adjacency for the specified interface.
Default Access Level
15
Command Syntax
configure interface link-aggregate <0-9[.0-254]> isis circuit-type <level1-enum2>
configure interface link-aggregate <0-9[.0-254]> isis circuit-type no
Supplemental
Information
The Level 1 adjacency may be established if there is at least one area address in common between this system and its neighbors.
To reset the circuit type, use the no option.
Parameters
<0-9[.0-254]>
LAG identifier <lag[sub interface]>
<level1-enum2>
Specifies the type of adjacencies to be formed on this interface. Valid range is level-1, level-1-2, or level-2. If no value is specified,
then value is set to level-1-2.
