Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure packetcable

Purpose

Enables all PacketCable (both DQoS and Multimedia) services on the C4 CMTS.

Default Access Level

Command Syntax

configure packetcable

configure packetcable no

Supplemental

Information

Note: By default, PacketCable services are disabled on the CMTS. When PacketCable services are disabled, the CMTS will disallow

any PacketCable signaling connections using the Common Open Policy Service (otherwise known as COPS) from the Call

Management Server (CMS). As a result, all PacketCable call requests will fail.

To disable all PacketCable services on the CMTS, use the no option.
