Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure interface cable-mac * cable downstream-bonding-group * attribute-mask

value

Purpose

Configures the attribute mask encoding for bonding group.

Default Access Level

Command Syntax

configure interface cable-mac <mac> cable downstream-bonding-group <int> attribute-mask value <value>

configure interface cable-mac <mac> cable downstream-bonding-group <int> attribute-mask value <value> no

Supplemental

Information

To remove the attribute mask, use the no option.

Parameters

<mac>

The MAC identifier. Valid numbers are 0-415.

<int>

Static bonding group identifier. Valid range is 1-65535.

<value>

Attribute mask. This is a hex string (must be greater than the default of 0x80000000)

Related Commands

show cable bonding-group-status (page 2637)
