Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure interface cable-mac * cable downstream-bonding-group * reseq-warning-

threshold

Purpose

Configures the resequence warning threshold for dynamic DSIDs on the specified cable-mac.

Default Access Level

Command Syntax

configure interface cable-mac <mac> cable downstream-bonding-group <name> reseq-warning-threshold <time>

configure interface cable-mac <mac> cable downstream-bonding-group <name> reseq-warning-threshold

[<time>] no

Supplemental

Information

To disable, use the no option.

Parameters

<mac>

The MAC identifier. Valid numbers are 0-415.

<name>

Name assigned to the bonding group.

<time>

Resequence wait time in hundredMicroseconds. Valid range is 1-179 or 255. The default value is 255.
