Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure route-map * match metric

Purpose

Configure routes that match the metric of the specified route.

Default Access Level

Command Syntax

configure route-map <word> match metric <int>

configure route-map <word> match metric [<int>] no

Supplemental

Information

To disable this function, use the no option.

Parameters

<word>

Name of this route-map

<int>

Metric value
