Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

show controllers cable-mac

Purpose

Displays cable-mac controller information.

Default Access Level

Command Syntax

show controllers cable-mac <mac> [<upstream | downstream>] [detail] [counts]

Supplemental

Information

N/A

Parameters

<mac>

MAC ID

upstream

Displays upstream information.

downstream

Displays only data associated with downstreams.

[detail]

Displays detailed information.

[counts]

Displays cable interface counts.
