Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure packetcable voice-limits reserved-normal

Purpose

Defines the minimum percent of the downstream and upstream channel bandwidth reserved for normal voice.

Default Access Level

Command Syntax

configure packetcable voice-limits reserved-normal <percent> [downstream | upstream]

Supplemental

Information

Rules/Limits on Percentage Values:

Maximum range 0-90

allowed-total >=reserved normal + reserved-emergency

allowed-emergency reserved-emergency

Parameters

The percentage reserved for normal voice use. See table above.

[downstream|upstream]

Direction of channel bandwidth.

Related Commands

configure packetcable voice-limits set-all (page 2231)
