Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

configure ipv6 nd state searching global-max-rate

Purpose

Configures the maximum Neighbor Discovery transmit rate for all searching IPs.

Default Access

Level

Command Syntax

configure ipv6 nd state searching global-max-rate <0-65535>

configure ipv6 nd state searching global-max-rate [<0-65535>] no

Supplemental

Information

To reset, use the no option.

Parameters

<0-65535>

The rate, in packets/second, for ARPs.
