Chapter 3: C4/C4c CMTS Specifications

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

RF Electrical Specifications

The following table lists the downstream RF electrical specifications for the C4 and C4c CMTSs.

Table 4. Downstream RF Electrical Specifications

Specification

16D or XD CAM

Center frequency range supported:

57 - 999 MHz

Frequency step size:

125 kHz

Modulation types

64QAM, 256QAM

Downstream channel width:

North America (Annex B)

Europe (Annex A)

Europe (using Annex B)

6 MHz

8 MHz

6 MHz with 6 or 8 MHz channel spacing

Annex B symbol rates in Msym/sec

64QAM: 5.056941

256QAM: 5.360537

Annex A symbol rate in Msym/sec

64QAM or 256QAM: 6.952

Raw Bit Rate

Annex B: 64QAM

256QAM

Annex A: 64QAM

256QAM

30.342 Mbps

42.884 Mbps

41.712 Mbps

55.616 Mbps
