Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

[authentication-key

<pwd>]

Authentication string: 8 characters for simple text, 16 characters for message-digest. Authentication type must be specified if key is

specified

[authentication

<simple | message-

digest | null>]

Authentication type: message-digest (MD5); simple; or null (none)
