Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

[notify-filter <std-

filter-profile|

userdefined-filter-

profile>]

The filter profile to be used for a standard filter or user-defined filters to generate notifications.

[filter <subtree oid

| name>]

Filter subtree OID or the name of the notification object to be included. Currently, the only supported notification name is

"coldstart".

[taglist <value>]

The list of tag values which are used to select target addresses.
