Chapter 46: Command Line Descriptions

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

tftpstart

Config file download has started

tftpdone

Config file download process has been completed

registering

CMTS has received a registration request from the CM

frwddisable

Registration complete but forwarding prohibited

rfmuteall

Mute all channels

non-operational

Any state other than operational

online-d

Registered with Net Access disabled

Related Commands

show cable modem (page 2670)
