Arris C4 - Page 379

To Next Page

To Previous Page

Chapter 13: CAM Sparing

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

Type of PIC

Faceplate Label

Downstream sparing PIC:

PIC-CAM 16D (SPARE)

Downstream PIC:

PIC-CAM 16D

Upstream sparing PIC:

PIC-CAM (SPARE)

Upstream odd slot:

PIC-CAM (O)

Upstream even slot:

PIC-CAM (E)
