Chapter 18: Baseline Privacy Interface (BPI)
STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide
© 2016 ARRIS Enterprises LLC. All Rights Reserved. 605
The BPI specification requires ALL BPI parameters to be defined in the BPI configuration file sent
to the CM during registration. One or more values have not been defined in the CM’s config file.
Action: Correct CM’s config file by defining ALL BPI parameters. Re-register the modem.
Invalid Baseline Privacy Configuration Setting value.
Problem: During registration, one or more BPI configuration values has been determined to be out
of range. The trap will only display the FIRST value detected out of range.
Action: Correct CM’s config file by verifying ALL BPI parameters are within operating ranges. Re-
register the modem.
Note: Two of the configuration value valid ranges depend on global BPI card settings. TEK grace
time MUST be LESS THAN one half the BPI base table TEK lifetime. Authorization grace time MUST
be LESS THAN one half the BPI base table Authorization lifetime.
Auth Reject – No information
Problem: The respective modem’s authorization request has been rejected.
Action: The internal C4/c CMTS reason for the reject will be displayed in the modem’s respective
auth reject error string MIB table entry. If the reason can be corrected, fix and reboot the modem.
Auth Reject – Unauthorized CM
Problem: The respective modem’s authorization request has been rejected. The modem cannot
be validated and is therefore unauthorized.
Action: The internal C4/c CMTS reason for the reject will be displayed in the modem’s respective
auth reject error string MIB table entry. If the reason can be corrected, fix and reboot the modem.
Auth Reject – Unauthorized SAId
Problem: The respective modem’s authorization request has been rejected. The modem is
indicating its authorization for a flow it has not been authorized for.
Action: There is no corrective action that can be taken.
