Arris C4 - Page 811

To Next Page

To Previous Page

Chapter 28: PacketCable™ Services and Voice Applications

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

together in any combination. Specifically, the C4/c CMTS itself must communicate with the Call Management Server

(CMS), the Record Keeping Server (RKS), and the Delivery Function (DF) for various portions of signaling information.

Note: The IP addresses and ports for RKS and DF are configured on the CMS, not on the C4/c CMTS.
