Chapter 3: C4/C4c CMTS Specifications

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

Standard

Status

Notes

Complies with the following subset of PacketCable Multimedia

Specification,

PKT-SP-MM-I04-080522:

 Support for Bonded Unicast Flows

 Attribute-based Channel Selection

 Support for User Identifier

 Addition of Max Concatenated Burst to the BE Traffic Profiles

 Handling of DOCSIS 3.0 Peak Rate TLV

 DOCSIS 3.0 Additions of Sequence and Segment Numbers

 Packet Cable Update of Major/Minor Version for I04

 Traffic Profile: Upstream Drop

DOCSIS Set-top

Gateway (DSG)

DOCSIS 2.0 qualification at Cert-

wave 32 includes DSG
