Chapter 31: Load Balancing

STANDARD Revision 1.0 C4® CMTS Release 8.3 User Guide

direct

0x08

All of the above init techniques are supported for D1.1 and D2.0 cable modems.

The C4/c CMTS supports several cross-checks when setting the MIB value, including:

 The Mac Domain IfIndex must exist.

 A downstream must exist and match the docsLoadbal3ChgOverGroupdownFrquency.

 The upstream channel ID must exist on the C4/c CMTS on the specified Mac Domain.

The command will be rejected with an error message if any of these items are invalid when a ChgOverGroupCommit is

attempted.

The following list summarizes the load balancing rules for various types of CMs:

 DOCSIS 1.0 CMs: No DCC is allowed.

 DOCSIS 1.1 and 2.0 CMs: DCC with all init techniques is supported.

 DOCSIS 2.0b and 3.0 CMs: DCC using the reinit-mac technique.
