CAPINTEC, INC. CAPTUS
®
4000e
November 16 THYROID UPTAKE 7-11
1. On Figure 7-1 Thyroid Uptake Main Screen, select the Add button. The Patient
Information screen will appear as shown in Figure 7-9, with information to be entered in
three sections.
Figure 7-9
• Click in the text box or use the Tab key to move from one text box to another. To
select from the drop-down list, use the or arrow keys.
2. Enter the Patient Information.
• Input the Last Name, First Name, Date of Birth, Patient ID and Physician.
• In the Sex box, select male or female from the drop-down list or press the M or F key.
• In the Select Protocol box, select a pre-defined protocol from the drop-down list for
the Thyroid Uptake procedure.
Note: Any combination of up to 20 alphanumeric characters can be used for the First
Name, Last Name, ID and Physician. Fields not in bold are optional.
Note: The Accession # field will only be displayed if the valid Cap-DICOM license is
entered in your system.
3. Next, input the Dosage Information.
• The isotope associated with the selected protocol will appear at the top of this
section. The fields in this section of the screen will vary according to the Dose
Administration mode selected in the protocol as follows:
